Max150 150kW 300Nm Motor/Inverter Kit

Max150 150kW 300Nm Motor/Inverter Kit

Specification


  • DC voltage input 280-450 VDC
  • Max peak power 150 kW
  • Nominal power 70 kW
  • Max torque 300 Nm
  • Max RPM 12,000
  • Protection level IP67
  • Operating temperature -40 to +180 degrees Celsius
  • Water cooled motor and inverter
  • Weight: Motor: 55kg / Inverter: 8kg


Features


  • Optional inline and transverse reduction boxes available.
  • Motor Coupling included


Available CAD Files
